  • DRV8434S SPI Stepper Motor Driver Carrier - stepper motor driver with DRV8434A system and potentiometer (soldered)
ID: 1181797
zł58.84
Tax included

zł47.84 tax excl.

Module with a stepper motor driver based on the DRV8434A system. It allows the bipolar motor to be supplied with current up to 1.2 A per phase and with a voltage from 4.5 V to 45 V. Communication via the SPI interface. Pololu 3767

4 weeks
On request
Kamami is the official distributor of electronic modules and Pololu robotic parts. All products of this brand in our offer are original and come directly from the manufacturer.

Description

Module with a stepper motor driver based on the DRV8434A system. It allows you to supply a bipolar motor with a continuous current of up to 1.2 A per phase (up to 2 A with instantaneous current) and a voltage from 4.5 to 48 V. It can work with 1.8 V, 3.3 V and 5 V systems, which makes it that it is a universal controller for a wide range of applications.

The module uses the SPI interface and has numerous built-in functions that allow for full configuration of the controller. For the motion control itself, it can use the SPI interface or a popular control interface based on two inputs: STEP, which corresponds to one step of motor rotation, and DIR, which determines the choice of direction. The layout offers 11 resolutions from full step to 1/256 step. The maximum output current is regulated by a potentiometer, and the current current through the SPI interface, which protects the motor against damage. The controller has a number of built-in protections, including overheating and overvoltage.

Features

  • Supply voltage range from 4.5 V to 48 V
  • Current up to 1.2 A continuously per phase without additional cooling (temporary 2 A)
  • It can work directly with 1.8V, 3.3V and 5V systems
  • SPI interface for configuration and control
  • Optional STEP / DIR control interface
  • Step resolutions: full step with 100% current, full step with 70% current, 1/2 step, 1/4 step, 1/8 step, 1/16-steps, 1/32-steps, 1/64-steps, 1/128 steps, 1/256 steps
  • Eight customizable decay modes including dynamic decay and ripple control modes
  • Regulation of the maximum current with the potentiometer, and the current current with the SPI
  • Integrated blockage detection
  • Overheating thermal shutdown, overcurrent protection, open load detection, undervoltage lockout and overvoltage protection
  • Built-in EMI reduction systems
1181797

Data sheet

Output current
1,2 A
Number of channels
1
Supply voltage min
4,5 V
Supply voltages max
48 V
