TMC2208 stepper motor driver module
ID: 1178233
5906623441716
zł20.43
Tax included
zł16.61 tax excl.
Module with TMC2208 stepper motor driver. It enables control with a supply voltage ranging from 5.5 to 34 V and a current of up to 1,2 A
Description
The module with the TMC2208 bipolar stepper motor driver, which enables control with a supply voltage ranging from 5.5 to 35 V and a current of up to 1,2 A. It is controlled via the STEP/DIR interface, and a single-wire UART interface is used to configure advanced system options. The controller has numerous safety systems built in, including the advanced TRINAMIC StealthChop2 circuit breaker for silent operation, maximum efficiency and the best torque of the engine, and the SpreadCycle system for highly dynamic movement during acceleration. The configuration of the system is stored in the non-volatile OTP memory. The module is perfect for projects that require precise control of a stepper motor, e.g. 3D printers or home automation.
Features
- Bipolar stepper motor control: 1,2 A RMS
- STEP/DIR interface
- Smooth operation of 256 microstepping
- StealthChop2 system: quiet engine operation
- SpreadCycle System: dynamic motor control circuit breaker
- Low-power standby mode
- Passive braking, free movement and automatic shutdown
- UART and OTP Single Wire for advanced configuration options
- Integrated pulse generator for independent movement
- Full protection and diagnostics
- Power supply: 5.5 to 35 V
Kit contains
- Module with the TMC2208 controller
- Radiator
- Cable
1178233
Data sheet
- Output current
- 1,2 A
- Number of channels
- 1
- Supply voltage min
- 5,5 V
- Supply voltages max
- 35 V
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
