New products
zł74.04 tax excl.
Extension board with stepper motor controller based on the STSPIN820 system. Ideally suited for use, among others in 2D / 3D printers, robots, cameras. Pololu 2879
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Stepper motor controller based on the STSPIN820 system from STMicroelectronics. The controller offers micro-shifts with a step up to 1/256 degrees and a wide operating range of 7 ... 45 V. It can supply up to about 0.9 A per phase in a continuous manner without radiator or cooling (max. 1.5 A). The module has soldered goldpin connectors.
properties
- A simple step and direction control interface
- Eight different degrees of resolution up to 256 microstep: full step, half step, 1/4 step, 1/8 degree, 1/16 degree, 1/32 degree, 1/128-step and 1/256-step
- Adjustable current control allows you to set the maximum output power
- Thermal over-temperature shutdown, overcurrent cut-off and short-circuit protection
- Engine power supply: 7 ... 45 V
- Current efficiency 0.9 A (1.5 A) max
- Works with 3.3 V and 5 V systems
- Dimensions: 15.5 x 20.5 mm
- Weight: 1.4 g
Sample module connection
Data sheet
- Output current
- 900 mA
- Number of channels
- 2
- Supply voltage min
- 7
- Supply voltages max
- 45 V
