KAmod DMX512 - USB-DMX512 Converter with Galvanic Isolation
ID: 1188018
5906623432882
zł117.90
Tax included
zł95.85 tax excl.
KAmod DMX512 is a DMX signal converter that enables communication between a computer and a stage lighting system. It is equipped with full galvanic isolation, supports up to 512 devices, has a transmission range of 1200 m, is powered via a USB-C port, and is compatible with various programs, making it ideal for professional use in theaters, clubs, and concerts
Description
KAmod DMX512 is a device used for data transmission between a computer and a DMX standard lighting system, such as spotlights, light effects, or moving heads. It allows control over the parameters of devices, including brightness, color, mode, and special effects, through special software or applications. The interface works with many free programs (virtual lighting consoles), which can be used to create elaborate and professional lighting scenes, enriching any event, diversifying theatrical plays, or creating unique musical performances. Additionally, full galvanic separation eliminates any disturbances that could affect the converter's stability, ensuring reliable operation. This product is an excellent solution for anyone wanting to enhance the quality and attractiveness of their performance through precise control over lighting in theaters, clubs, concerts, exhibitions, and many other places.
Features
- Full galvanic separation up to 1 kV
- Supports up to 512 devices
- Transmission range of 1200 m
- Powered directly from a USB port - USB-C connector
- Device connection - 3-pin XLR socket
- Indicator for the operation of separating circuits - green LED (PWR)
- DMX transmission indicator - blue LED (DMX)
- Compatible with USB1.1 and 2.0 (emulated COM port)
- Virtual serial port drivers for Windows and Linux
- Compliant with "Enttec Open DMX" standard
- Works with numerous programs (including free ones like Freestyler DMX, QLC+ DMX512 Light Control, and many others)
- Dimensions: 75 x 34 x 29 mm
