zł11.92 tax excl.
The current measurement with the value 0-20A is carried out by the ACS712-05 system based on the Hall effect. The sensitivity of the system is 100mV / A (analogue signal) .modACS712-20
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
The 0-20A current sensor module based on the ACS712-20 system that uses the Hall effect to measure.
properties
- Current measurement: 0-20A
- Sensitivity: 100 mV / A
- Power supply: 5 V
- Output: analog
- Dimensions: 31 x 13 x 12 mm
