Current sensor module (0 - 5A) with ACS712-05
ID: 232869
5906623441273
zł8.95
Tax included
zł7.28 tax excl.
The current measurement with a value of 0 - 5A is realized by the ACS712-05 system based on the Hall effect. The system sensitivity is 185mV / A (analog signal).
Description
The 0-5 A current sensor module based on the ACS712-05 system that uses the Hall effect to measure.
properties
- Current measurement: 0-5 A
- Sensitivity: 185 mV / A
- Output: analog
- Power supply: 5V
- Dimensions: 31 x 13 x 12 mm
To download
232869
Data sheet
- Interface
- Sygnał analogowy
- Zakres pomiarowy
- 0 - 5 A
- Sposób podłączenia
- Szeregowy
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
