Gravity: URM09 Analog Ultrasonic Sensor - analog ultrasonic distance sensor (5m)
ID: 581655
5906623434107
zł49.83
Tax included
zł40.51 tax excl.
Ultrasonic distance sensor with a range of up to 5 m with an analog output The module is supplied with the voltage from 3.3 to 5.5 V. DFRobot SEN0307
Description
Ultrasonic distance sensor with a range of up to 5 m and a resolution of 1 cm. It allows you to measure the distance from objects with a measurement frequency of up to 30 Hz with built-in temperature compensation. The sensor has an analog output. The module is supplied with the voltage from 3.3 to 5.5 V. The user manual and sample programs are available on the Wiki website.
Measuring angle
Features
- Range: 2 cm to 500 cm
- Resolution: 1 cm
- Accuracy: 1%
- Measurement frequency: 30 Hz
- Analog output
- Distance Formula: Distance=Vout(mV)×520/Vin(mV)
- Power supply: 3.3 to 5.5 V
- Current consumption: 20 mA
- Operating temperature range: -10 ℃ to 70 ℃
- Dimensions: 47 x 22 mm
Kit contains
- Ultrasonic distance sensor URM09
- Gravity PH2.0-3P cable
581655
Data sheet
- Interface
- Sygnał analogowy
- Type of sensor
- Ultrasonic
- Minimum distance
- 2 cm
- Maximum distance
- 500 cm
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
