KAmod ESP32 POW+RS485 - Evaluation board with ESP32-WROOM Wi-Fi module and RS485 interface
ID: 1191671
5906623488070
zł89.90
Tax included
zł73.09 tax excl.
The KAmod ESP32 POW+RS485 board equipped with the ESP32-WROOM module supports 2.4 GHz Wi-Fi, RS485 communication, also has a USB-UART converter, an efficient power supply system and a 40-pin connector compatible with Raspberry Pi, making it an ideal solution for home and industrial automation
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
The KAmod ESP32 POW+RS485 board contains the ESP32-WROOM module, which enables communication in a 2.4 GHz Wi-Fi wireless network. A USB-UART converter with a USB-C connector was used to program the ESP32. The module is connected to the RS485 interface - a popular solution in home and industrial automation, enabling communication via a 2-wire twisted pair, e.g. in the MODBUS standard. The board is complemented by an efficient power supply system, which operates at an input voltage of 8 to 32 V, and provides stabilized voltages of 5 V and 3.3 V with significant current efficiency. The design of the board corresponds to the SBC of the Raspberry Pi family - it has dimensions of 81x56 mm, and all important I/O ports and supply voltages have been led out on a characteristic 40-pin connector.
Features
- ESP32-WROOM module enabling communication in a Wi-Fi network in the 2.4 GHz band
- Integrated UART-USB converter with a USB-C connector enabling programming of the ESP32 system
- RS485 interface for Half-duplex communication with a maximum speed of 1 Mbps
- Maximum number of devices connected to the RS485 bus: 64
- Adapted to a supply voltage in the range of 8...32 V
- Provides a stabilized voltage of 5.1 V with a continuous current of up to 3 A and a short-term current of up to 5 A
- Provides a stabilized voltage of 3.3 V with a continuous current of up to 1 A and a short-term current of up to 2 A
- Overvoltage, overload and thermal protection
- All important I/O ports and supply voltages have been led out to the 40-pin connector in the Raspberry Pi standard
- Board dimensions: 81 x 56 mm, height approx. 20 mm
