ID: 1203980
zł60.37
Tax included

zł49.08 tax excl.

Development board based on the ESP32-S3R8 microcontroller equipped with a 1.47″ IPS display with a resolution of 172 × 320 px. The module supports 2.4 GHz WiFi and Bluetooth Low Energy 5 connectivity and integrates 16 MB Flash memory and 8 MB PSRAM. The design also includes a 6-axis IMU sensor, TF card slot, and a USB Type-C connector for power supply and programming. Waveshare ESP32-S3-LCD-1.47B

6 weeks
Awaiting delivery
Kamami is the official distributor of Waveshare displays, accessories and modules.

Description

Development board based on the ESP32-S3R8 microcontroller featuring a dual-core Xtensa LX7 processor operating at up to 240 MHz. The chip supports 2.4 GHz WiFi (802.11 b/g/n) and Bluetooth Low Energy 5 connectivity. Integrated 16 MB Flash memory and 8 MB PSRAM enable more advanced IoT applications and graphical user interfaces.


The board integrates a 1.47″ IPS display with a resolution of 172 × 320 px capable of displaying 262K colors. The ST7789 display driver and SPI interface support graphical user interfaces, including applications based on the LVGL library.

The design also includes a 6-axis QMI8658 IMU sensor, a TF card slot for external storage, and a USB Type-C connector used for power supply, USB communication, and firmware uploading. An onboard power management circuit supports connection of a 3.7 V Li-Po battery, while GPIO headers allow expansion with additional modules. The standard version is supplied without pre-soldered headers.

p1203980-ESP32-S3-LCD-1.47B-details-intro.jpgp1203980-ESP32-S3-LCD-1.47B-details-inter.jpg

  1. ESP32-S3R8 - Dual-core processor, up to 240MHz running frequency
  2. 16MB Flash
  3. RGB LED - with onboard clear acrylic sandwich panel to achieve cool color changes
  4. ME6217C33M5G - Low dropout regulator, 800mA output (Max.)
  5. QMI8658 - 6-Axis IMU
  6. Charging management circuit
  7. Onboard ceramic antenna
  8. System battery interface - for connecting 3.7V Lithium battery, supports charging and discharging
  9. TF card slot
  10. RESET button
  11. BOOT button
  12. Type-C interface - for power supply, USB communication, and firmware downloading

Features

  • ESP32-S3R8 microcontroller
  • Dual-core Xtensa LX7 processor up to 240 MHz
  • 2.4 GHz WiFi 802.11 b/g/n support
  • Bluetooth Low Energy 5 and Bluetooth Mesh
  • 16 MB Flash memory
  • 8 MB PSRAM
  • 1.47″ IPS display
  • Resolution 172 × 320 px
  • 262K display colors
  • ST7789 display driver
  • 3-wire SPI display interface
  • 6-axis QMI8658 IMU (accelerometer and gyroscope)
  • TF card slot (microSD)
  • Built-in RGB LED
  • USB Type-C connector for power, communication, and programming
  • 3.7 V Li-Po battery charging circuit
  • Onboard ceramic antenna
  • ME6217C33M5G LDO regulator up to 800 mA
  • BOOT and RESET buttons
  • GPIO headers for external modules

Kit includes

  • 1 × Waveshare ESP32-S3-LCD-1.47B development board
  • 2 × pin header strips for soldering
