ESP32-S3-Pico-M board with ESP32-S3 Wi-Fi/BLE module and connectors - Waveshare 24023
ID: 1184845
5906623423590
zł43.60
Tax included
zł35.45 tax excl.
Espressif ESP32-S3 WiFi and Bluetooth LE module board. It offers 16 MB of flash memory and 2 MB of SRAM. The pinouts are compatible with the HAT modules for the Raspberry Pi Pico. Waveshare ESP32-S3-Pico-M
Description
The Espressif ESP32-S3 WiFi module board features 16 MB Flash memory, 2 MB PSRAM and an integrated WiFi 802.11 b/g/n transceiver and Bluetooth supporting BLE 5 and Bluetooth Mesh. A 3.3 V inverter with up to 2 A current capability and a 2.4 GHz ceramic antenna are included on the board. The 27 GPIO pins provide the user with analogue inputs and I2C, UART, SPI and DVP interfaces. The pinout and raster is compatible with HAT modules dedicated to the Raspberry Pi Pico, allowing the user to take advantage of the wide range of extension modules available. The board uses a USB type C connector for programming.
| 1. ESP32-S3R2 | 6. HUB controller CH334F |
| 2. Antenna 2,4 GHz | 7. USB-UART converter CH343P |
| 3. Flash W25Q128JVSIQ | 8. MP28164 DC-DC Converter |
| 4. BOOT button | 9. USB type C connector |
| 5. RESET button | 10. LED indicator |
The board offers great potential in the field of IoT systems. It can also be programmed using the Arduino IDE, ESP-IDF or CircuitPython. Full documentation is available on the product page.
Features
- Xtensa 32-bit LX7 240 MHz dual-core processor
- Integrated 512 kB SRAM, 384 kB ROM, 16 MB Flash, 2 MB PSRAM
- Wi-Fi 2.4 GHz - 802.11b/g/n
- Bluetooth LE 5, Bluetooth Mesh
- Ceramic antenna
- MP28164 3.3 V 2 A DC-DC converter
- Optimised power supply for low power consumption
- Power supply: USB Type C
- Built-in USB OTG Full-Speed interface, LCD interface (8-bit RGB/8080/6800 serial), DVP camera interface (8-bit - 16-bit)
- 27 GPIO pins, including ADC, UART, SPI, I2C, PWM
- Pin spacing compatible with Raspberry Pi Pico HAT modules
- Dimensions: 51 x 21 mm
