DC axial fan 4,32W 80x80x25 mm
ID: 1193599
5902186308060
zł29.90
Tax included
zł24.31 tax excl.
The SUNON 80x80x25mm DC axial fan offers high cooling performance, reliability thanks to Vapo bearings and an autorestart function, making it an ideal solution for applications requiring intensive cooling and durability in a compact form. Sunon PF80252V1-1000U-A99
Description
The SUNON axial fan with dimensions of 80x80x25 mm is a compact cooling device, designed to be powered by direct current (DC) in the voltage range from 10 to 27.6 V. With a power of 4.32 W and a rotational speed of 4800 rpm, the fan offers high efficiency 101.4 m³/h, making it ideal for applications requiring intensive cooling. Despite its efficiency, it generates noise of 44.7 dBA. The fan is equipped with Vapo bearings, which ensure reliability and long service life. The housing and impeller are made of thermoplastic, which guarantees resistance to difficult working conditions. The product meets the ECE R-118 and UL94V-0 flammability safety standards, which emphasizes its high quality and safety. An additional autorestart function and a brushless DC motor increase the reliability of the fan in various applications.
Properties
- Fan type: DC axial
- Operating voltage: 10...27.6 V
- Size: 80x80x25 mm
- Power consumption: 4.32 W
- Rated current: 0.18 A
- Productivity: 101.4 m³/h
- Noise level: 44.7 dBA
- Rotational speed: 4800 rpm
- Bearing type: Vapo
- Insulation resistance: min. 10 MΩ
- Rotor material: Thermoplastic
- Housing material: Thermoplastic
- Insulation class: A
- Terminals: Cable x2 (length 0.315 m, size 24 AWG)
- Operating temperature: -10...70°C
- Static pressure: 10.41 mm H2O
- Flammability class: ECE R-118, UL94V-0
- Additional functions: Autorestart
- Fan motor: Brushless DC
1193599
Data sheet
- Voltage
- 10 - 27,6 V
- Power
- 4,32 W
- Length
- 80 mm
- Width
- 80 mm
- Height
- 25 mm
- Weight
- Other
- Noise level
- 44,7 dBA
- Air flow efficiency
- 101,4 m³/h
- Rated current
- 180 mA
- Fan type
- Axial
