zł39.52 tax excl.
OSD (On-screen Display) module dedicated to FireBeetle boards. It allows you to add subtitles and graphics to the image downloaded from the camera. DFRobot DFR0515
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
OSD (On-screen Display) module dedicated to FireBeetle boards. It is based on menu display technology that allows you to add various characters and graphics on the screen. The module uses the OSD chip AT7456E, which is a single-channel OSD module, equipped with features such as a video driver, sync separator and video switch. It is equipped with 512 byte EEPROM memory programmable by the user. After connecting to a video source (AV signal), the display has a resolution of 540x192 pixels, on which it is able to show 16x30 characters. Users can also use the font library to display characters and images. The module will be used in monitoring devices and home automation. Full documentation is available on the product page.
Features
- 512-byte EEPROM memory
- Displaying up to 16x30 characters
- Support video output attenuation compensation
- Built-in sync generator and support for external sync signal input
- Compatible with NTSC and PAL
- Built-in character set
- Working voltage: 3.3V to 5V
- Working current: 75 mA
- Character display: 16x30
- Resolution: 540x192 px
- White color
- Signal source: AV I / O
- Communication interface: SPI
- Working temperature: -10 ℃ to 85 ℃
- Dimension: 58 x 29 mm
Kit contains
- FireBeetle OSD Character Overlay module
- 2 x AV cable for JST-2P
- 2 x 18-pin female goldpin connector
- 2 x male goldpin 18-pin connector
- 4-pin male goldpin connector
