DFRobot Gravity Analog soil moisture sensor
ID: 561337
5902186311992
zł27.53
Tax included
zł22.38 tax excl.
Earth humidity sensor with analogue output, supplied with 3.3 to 5.5 V voltage with Gravity connector. DFRobot SEN0193
Description
Soil moisture sensor with analogue output, supplied with voltage in the range 3.3-5.5 V. The voltage level of the analog output increases in proportion to the ground moisture level. The module is made of anticorrosive material, which significantly extends the life of the product. The sensor can be used in an automatic watering system. The module has a 3-pin Gravity connector compatible with DFRobot sets.
Attention!
The elements on the plate are not waterproof and should not be exposed to moisture outside the red line. In the event of danger of contact with water, the elements should be protected with a heat shrinkable tube, for example.
The elements on the plate are not waterproof and should not be exposed to moisture outside the red line. In the event of danger of contact with water, the elements should be protected with a heat shrinkable tube, for example.
properties
- Output voltage: 0-3 V
- Operating current: 5 mA
- Interface: PH2.0-3P (Gravity)
- Operating voltage: 3.3-5.5 V
- Dimensions: 98 x 23 mm
- Weight: 15 g
Included
- Moisture sensor module
- Gravity connection cable
561337
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
You might also like
The soil moisture sensor with comparator LM393 has an analogue and digital output (with adjustable switching threshold). modHUM
zł8.03
24h
Available quantity: 14
Available
Soil moisture sensor based on soil resistivity meansurement
zł12.28
24h
Available quantity: 6
Available
Expansion board for Arduino, allows easy connection of XBee modules, has separate outputs for I2C, SPI and UART buses. The built-in 3.3V voltage stabilizer and operating mode switch make it easier to program the Arduino when the XBee module is connected to the sockets. DFRobot DFR0265
zł21.65
24h
Available quantity: 2
Available
Gravity: IO Expansion & Motor Driver Shield is an Arduino compatible expansion board that provides digital I / O ports, analog I2C, SPI and UART interfaces, as well as a DC motor driver. DFRobot DFR0502
zł65.65
24h
Available quantity: 3
Available
Other products in the same category (16)
Sensor dedicated to the measurement of nitrogen content in the soil. Allows you to monitor and analyze the level of the element in the soil, and thus optimize fertilization and improve cultivation processes
zł271.58
4 weeks
No product available!
Module with a soil moisture sensor for the M5Stack sets. It has an analog output and a digital output with adjustable reaction threshold. M5Stack U019
zł19.90
24h
Available quantity: 2
Available
Capacitive soil moisture sensor with analog output (Grove connector). The probe has a pointed tip, which allows it to be easily inserted into the ground. Cytron MAKER-SOIL-MOISTURE
zł19.20
4 weeks
No product available!
The FC-28 sensor is used in automatic irrigation systems, IoT projects, and educational experiments involving soil moisture measurement. It enables accurate monitoring of crop conditions and optimizes water consumption
zł2.90
24h
Available quantity: 50
Available
A robust sensor for approximate measurement of nitrogen, phosphorus and potassium (NPK) levels in soil, ideal for precision farming and field applications. With a rugged design (IP68), RS485 MODBUS-RTU communication and a wide power supply range, it allows easy integration with Arduino-type systems and operation in harsh environmental conditions. DFRobot SEN0605
zł391.84
24h
Available quantity: 1
Available
Soil moisture sensor based on soil resistivity meansurement
zł12.28
24h
Available quantity: 6
Available
A set of three capacitive soil moisture sensors for a home automatic irrigation system. Pimoroni PIM520
zł94.03
4 weeks
No product available!
Soil moisture sensor with analog output. The module comes with a probe with metal tips.
zł17.01
4 weeks
No product available!
Soil moisture sensor with analogue output. It has a shape resembling a fork, which makes it easy to put it in the ground. The voltage level of the analog output increases in proportion to the ground moisture level. The sensor can be used in an automatic watering system. Version with a 3.5 mm ARK connector. SEN-13637
zł47.42
24h
Available quantity: 2
Available
Soil moisture sensor dedicated to micro:bit. It is supplied with the voltage from 3.3 V to 5 V and communicates via an analog signal. SparkFun SEN-15272
