GT-24 - radio module NRF24L01+ with PCB antenna and u.FL connector
ID: 1185028
5906623450916
zł12.36
Tax included
zł10.05 tax excl.
The NRF24L01+ chip module for radio communication, which operates in the 2.4 GHz ISM band. It is used in various applications such as wireless sensors, remote control, wireless networks. It supports the Enhanced ShockBurst protocol, which provides automatic packet handling. It communicates via an SPI interface
Description
The NRF24L01+ module is a popular radio communication chip that operates in the 2.4 GHz ISM band. It is used in a variety of applications such as wireless sensors, remote control, wireless networks and many others. It offers a variety of data rates, including 250 kbps, 1 Mbps and 2 Mbps, allowing transmission speeds to be tailored to specific application requirements.
One of the most important features of the NRF24L01+ is its very low power consumption. In transmit (TX) mode with an output power of 0 dBm, it consumes only 11.3 mA, and in receive (RX) mode with a data rate of 2 Mbps, the power consumption is 13.5 mA. This makes it ideal for applications that require low power consumption, such as battery applications.
The module uses the Enhanced ShockBurst protocol, which provides automatic packet handling, meaning you don't have to worry about manually managing data packets. It communicates via SPI (Serial Peripheral Interface) with the microcontroller or other devices. This makes it easy to connect the module to different platforms. The board is equipped with a PCB antenna and a u.FL connector, which allows an external antenna connection if a longer range is required. The module offers a range of up to 1,000m, making it a suitable solution for applications requiring long-distance communication.
Features
- NRF24L01+ chip
- Operation in the 2.4 GHz ISM band
- Data rates of 250 kbps, 1 Mbps and 2 Mbps
- Very low power consumption:
- 11.3 mA TX at 0 dBm output power
- 13.5 mA RX at 2 Mb/s data rate
- 900 nA in off mode
- 26 µA in standby mode
- Built-in voltage stabiliser
- Enhanced ShockBurst protocol
- Automatic packet handling
- SPI interface
- PCB antenna and u.FL connector
- Range: 1000 m
- Power supply range: 1.9 to 3.6 V
- Dimensions: 30 x 14.5 mm
1185028
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
