KA-Nucleo-UniExp - expander (shield) compatible with Arduino/NUCLEO with Bluetooth 2.0+EDR, MEMS LIS35D and temperature sensor
ID: 234527
5906623432455
zł99.00
Tax included
zł80.49 tax excl.
Multifunctional expander (shield) for NUCLEO and Arduino equipped with Bluetooth 2.0+EDR (HC-05) interface, MEMS 3DoF LIS35, LED-RGB, joystick and analog STLM20 temperature sensor developed and produced by KAMAMI.
Description
KA-Nucleo-UniExp is a multifunctional expander (shield) for NUCLEO and Arduino boards. It is equipped with Bluetooth 2.0+EDR interface (HC-05), MEMS 3DoF LIS35, LED-RGB, 5-way joystick and analog temperature sensor STLM20.
Features
- Compatibility with NUCLEO and Arduino systems
- Embedded Bluetooth v2.0+EDR module with parameters:
- SPP Profile (Serial Port Protocol)
- Asynchronous transmission speed up to 2,1 Mb/s
- Synchronous transmission speed up to 1 Mb/s
- Embedded MEMS 3D accelerometer with I2C interface:
- Hardware address selector on bus
- Measurement range +/-2g or +/-8g
- Maximum measurement data rate 100/400 Hz
- On-board temperature sensor with analog output (-40…+85°C)
- On-board LED RGB
- On-board 5-way joystick
- Extended pins connector
- Dimensions: 55 x 55 x 20 mm
Kit content
- Assembled module board
234527
Data sheet
- Communication
- Bluetooth
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
