Adafruit Sparkle Motion Stick + Enclosure Kit – LED controller with enclosure, compatible with WLED
ID: 1198432
5902186316751
zł100.17
Tax included
zł81.44 tax excl.
Ready-to-use LED controller with ESP32 and enclosure, compatible with WLED. Wi-Fi support, 5V outputs, microphone, IR, NeoPixel, and screw terminals. Adafruit 6333
Description
The Adafruit Sparkle Motion Stick + Enclosure Kit is a complete LED controller based on the ESP32-MINI-1 module, housed in a durable, transparent protective case. It allows for easy control of LED strips (NeoPixel, WS2812, SK6812, etc.) over Wi-Fi using WLED software—no soldering, programming, or additional components required.
Simply plug the stick into a USB-C port, configure WLED, connect the LED strip, and you're ready to go—all in a compact and sleek enclosure.
Features
- Powered via USB Type-A – up to 5V at 2A
- 2A auto-resetting fuse protects the circuit from overcurrent
- ESP32 mini module with built-in antenna – fully WLED-compatible, featuring 4MB Flash, dual-core 240 MHz Tensilica processor, Wi-Fi, Bluetooth LE, and Bluetooth Classic
- USB–UART converter for easy programming
- Two signal outputs + 5V power and ground, both level-shifted to 5V logic
- Built-in I2S microphone for audio-reactive projects
- Integrated IR receiver simplifies remote control integration
- User button accessible even with the case on
- Built-in red status LED and RGB NeoPixel LED
- Screw terminal blocks for solder-free wiring
