zł317.01 tax excl.
LoRa module working on the 868 MHz frequency band with built-in RP2040 microcontroller, CH340 USB to UART converter, 74HC125V voltage level converter. SB Components 23240
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
GatePi is a low power data transmission board with built-in RP2040 microcontroller, CH340 USB to UART converter, 74HC125V voltage level converter and E22-900T22S chip, which covers the 868MHz frequency band. The user has 4 relays, an IPEX antenna connector and LoRaTM Spread Spectrum Modulation technology with automatic multilevel repeat. It can transmit data up to 5 kilometers.
The LoRa board can be used to operate industrial and domestic devices from a long distance. The remote power switch allows you to adjust the power of devices and control gadgets, lighting, irrigation systems, pumps, remote servers, towers, activate and deactivate security systems, and manage access to gates and doors.
Features
- 868 MHz frequency
- Power 22dBm
- 5 km range
- UART communication interface
- LoRa E22-900 module
- LoRa USB communication and RP2040 USB
- 4 opto-isolated relays
- Specification of the AC -10A/250V and DC -10A relay
Kit contains
- GatePi
- Antenna
