Crowtail-LoRa RA-08H – LoRaWAN communication module, 803–930 MHz, ASR6601, 1 km, 3.3–5 V
ID: 1201691
5902186331976
zł46.49
Tax included
zł37.80 tax excl.
Crowtail-LoRa RA-08H is an energy-efficient LoRaWAN communication module with the ASR6601 chip, enabling data transmission up to 1 km in the 803–930 MHz band. Ideal for IoT projects, automation and remote monitoring systems requiring long battery-powered operation.
Description
The Crowtail-LoRa RA-08H module enables long-range wireless data transmission using LPWAN technology. Equipped with the ASR6601 chip integrating an RF transceiver, modem and 32-bit RISC microcontroller, it supports LoRa, (G)FSK, BPSK and (G)MSK modulation. With high sensitivity down to –138 dBm and transmit power up to +22 dBm, the module is suitable for monitoring systems, building automation, logistics, irrigation systems and IoT solutions requiring energy-efficient long-distance communication.
Designed in the Crowtail standard, it allows easy connection to Arduino- and Crowduino-compatible platforms. It supports multiple sleep modes, including deep sleep with a current draw of 0.9 µA, making it ideal for battery-powered outdoor applications.
Properties
- Communication chip: ASR6601
- Operating frequency: 803–930 MHz
- Modulation: LoRa, (G)FSK, BPSK, (G)MSK
- High sensitivity: down to –138 dBm @ 125 kHz SF12
- Transmit power: up to +22 dBm
- Transmission range: up to 1 km (open conditions)
- Supported spreading factors: SF5–SF12
- Built-in memory: 128 KB Flash, 16 KB SRAM
- Supply voltage: 3.3–5 V
- Deep-sleep current: 0.9 µA
- Antenna connector: IPEX (1st generation)
- Programming/transmission mode switching
- Dimensions: 40 × 20 × 7.5 mm
Included
- Crowtail-LoRa RA-08H module
- Crowtail cable
- Antenna
