STEMMA QT Triple-axis Magnetometer - a module with a 3-axis MMC5603 magnetometer
ID: 1181301
5906623431335
zł31.73
Tax included
zł25.80 tax excl.
Module with a 3-axis magnetic field sensor MMC5603. Equipped with a STEMMA QT connector, it communicates via the I2C interface. Adafruit 5579
Description
A module with a 3-axis magnetic field sensor MMC5603 dedicated to measuring the Earth's magnetic field. It allows you to detect magnetic north. The sensor is usually combined with an accelerometer and a 6 DoF gyroscope to create a 9-DoF inertial measurement unit that can detect its orientation in space. It is powered with the voltage from 3.3 V to 5 V, and communication is via the I2C interface (STEMMA QT connector). Full documentation is available on the product page.
Features
- 20-bit data resolution for each measurement direction
- Field measurement ± 3 mT
- 1º course accuracy possible
- Measurement frequency: 1000 Hz
- Eliminates the offset error caused by thermal changes
- Supply voltage: 3 V to 5 V
- I2C interface
- I2C address: 0x30
- Dimensions: 25.4 x 17.8 x 4.6 mm
Kit contains
- STEMMA QT Triple-axis Magnetometer
- 6-pin goldpin male connector
1181301
Data sheet
- Interface
- I2C
- Type of sensor
- MMC5603
- Power supply voltage
- 3,3 - 5 V
