3-axis magnetometer module BMM150 - Waveshare 24657
ID: 1185239
5906623423682
zł29.56
Tax included
zł24.03 tax excl.
Module with a 3-axis magnetometer based on the BMM150 chip. It communicates via an I2C or SPI interface. Waveshare BMM150 3-Axis Magnetometer Sensor
Description
The BMM150 3-axis magnetometer module, which allows magnetic field measurements of ±1300 μT (x- and y-axis) and ±2500 μT (z-axis) with a resolution of 0.3 μT. Based on Bosch's proprietary FlipCore technology, it provides absolute orientation information with high measurement accuracy. Thanks to its small size, it is particularly suitable for course determination in drones. The module communicates via an I2C or SPI interface and is powered by 3.3 V or 5 V. Full documentation of the module with examples of use is available on the product page.
Features
- Measurement range: ± 1300 μT (x, y axis), ± 2500 μT (z axis)
- Resolution: 0.3 μT
- Accuracy: 30 μT
- I2C or SPI interface
- Programmable interrupt
- Zero-B offset: ±40μT/±2μT
- Supply voltage: 3.3 V or 5 V
- Current consumption: up to 500 uA
- Dimensions: 29 x 2 mm
Kit contains
- BMM150 3-Axis Magnetometer Sensor
- PH2.0 5-pin connector
1185239
Data sheet
- Interface
- SPI/I2C
- Type of sensor
- BMM150
- Power supply voltage
- 3,3 V/5 V
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
You might also like
Arduino Uno Rev3 is a popular board with Atmel ATmega328 microcontroller from the AVR family, there are 14 I / O lines, 6 PWM channels and 6 analog inputs. The additional ATmega16U4 microcontroller realizes communication via the USB interface. Arduino A000066
zł108.42
Delivery date unknown
No product available!
NUCLEO series starter kit equipped with STM32G474RE microcontroller (512 kB Flash, Cortex-M4), with built-in programmer-debugger ST-Link-V3E, equipped with connectors compatible with Arduino.
zł97.56
Delivery date unknown
No product available!
The latest version of the Raspberry Pi series: Raspberry Pi 4 model B with quad-core SoC (Broadcom BCM2711, Cortex-A72) working at 1.8GHz, 2GB RAM LPDDR4, Broadcom VideoCore VI.
zł220.90
Delivery date unknown
No product available!
Other products in the same category (16)
A module with a 3-axis magnetometer based on the BMM150 chip. It communicates via an I2C interface. DFRobot SEN0529
zł40.47
4 weeks
No product available!
Module with TLV493D 3-axis magnetic field sensor. Equipped with a STEMMA QT connector, it communicates via the I2C interface. Adafruit 4366
zł35.17
4 weeks
No product available!
The GY‑271 module with HMC5883L sensor is a precise digital compass offering three-axis magnetic field measurement, I²C communication, and 3 V–5 V operation. Suitable for robotics, navigation, and embedded systems requiring low power consumption and a compact form factor. GY‑271
zł9.70
4 weeks
No product available!
Complete kit for building a gradiometer, including two FG-3+ magnetometer sensors, a PCB board, Android-enabled software, and a mobile app. The kit allows for easy assembly and quick start-up of the device, which will immediately start displaying readings on the LCD after connection. Additional accessories, such as sensor holders, sensor tuning pipes, and a housing, provide convenience, safety, and precise adjustment of the device to use. SparkFun WIG-25530
zł1,992.69
3 weeks
No product available!
PmodCMPS2 is a module with a digital magnetometer based on the Memsic MMC34160PJ system. It has a resolution of 0.5 mG (within ± 16) and accuracy up to 1 °. For communication with the module, an I2C interface is provided on the 6-pin Pmod connector. Digilent 410-355
zł38.82
3 weeks
No product available!
A sensitive sensor of the magnetic field, operating in the range of ± 50 microtesels, which generates a rectangular signal proportional to the strength of the field, which facilitates its integration with microcontrollers. It is distinguished by high temperature stability and tenderness, which makes it ideal for precise magnetic field measurements in applications requiring reliability. Sparkfun Sen-25531
zł351.76
3 weeks
No product available!
Module with 3-axis magnetometer MAG3110, I2C, RoHS
zł54.58
24h
Available quantity: 3
Available
Module with a 3-axis magnetometer HMC5883L, which allows the measurement of the magnetic field in the range of ±8 Gauss. Communication via the I2C interface
zł14.76
24h
Available quantity: 6
Available
HMC5883L digital electronic compass 3-axis magnetoresistive sensor module with level converter, RoHS
