OP20-3 - 20X tip for SigOFIT Micsig 350MHz probe
ID: 1197270
zł1,398.90
Tax included
zł1,137.32 tax excl.
A 20X attenuation factor probe tip. Designed for Micsig probes from the SigOFIT series operating in the 100MHz, 200MHz and 350MHz frequency bands. Micsig OP20-3
Description
The 20X attenuation probe tip is designed to extend the measurement range of Micsig high-frequency probes. It enables operation at high voltages while ensuring safety and measurement accuracy. Thanks to its low input impedance, it minimizes the influence on the signal under test. Fully compatible with OIP350 probes, this tip is suitable for signal analysis up to 100 MHz, 200 MHz, and 350 MHz, both in laboratories and in field applications. Its compact design makes it easier to access hard-to-reach measurement points.
Features
- Attenuation ratio: 20:1 @0dB ±25V, 2:1 @20dB ±2.5V
- Maximum operating voltage: ±1000Vpp
- Input impedance: 4.47MΩ || 4pF
- Compatible with OIP350 probes
- Adapter type: MMCX
1197270
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
