NL-USBR-C-001 - module with relay and USB interface
ID: 1186925
5906623411696
zł238.03
Tax included
zł193.52 tax excl.
Module with one 5 V relay with a maximum switching current of 10 A. It communicates via a USB interface and does not require additional power supply. Numato Lab NLRL1001-A
Description
Module with one relay and 4 IO pins (3 with analog input function) supporting communication via USB. It can control devices with a current of up to 10 A. The USB interface makes it easy for the user to connect the module to any devices running Windows, Linux, Mac or embedded computers such as RPi. It comes with software that supports simple commands to control relays and read their status. When connected to a computer, the board appears as a serial port and can be operated by serial terminal applications such as HyperTerminal or Putty. Due to the fact that it uses 5 V relays, it does not require additional power supply (only via the USB port). It is perfect for automation systems. Full documentation is available on the product page.
Features
- 5V SPDT relay
- Maximum switching current 10 A
- 4 IO TTL 5V
- 3 analog inputs (multiplexed with IO)
- Resolution of analog inputs 10 bits
- USB interface with CDC support
- Relay contacts available on screw terminals
- It can be controlled using standard serial console applications
- Powered by USB port
- Dimensions: 70 x 40 mm
1186925
Data sheet
- Output current
- 10A
- Number of channels
- 1
- Executive element
- Przekaźnik
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
