Thermocouple converter module with AD8495 circuit
ID: 563091
5906623429431
zł78.08
Tax included
zł63.48 tax excl.
Thermocouple converter module based on the AD8495 circuit with an analogue output. Adafruit 1778
Description
The Analog Devices AD8495 system is so easy to use that all the information needed for its use fit on the PCB of this small module. The module cooperates with K type thermocouples, requires voltage supply in the range 3.18. V. OUT output is an analog output, it is enough to measure the voltage on this line, then calculate it according to the formula for temperature: Temperature = (Vout - 1,25) / 0.005 V, for example if the OUT output has a measured voltage of 1.5 V, the temperature is (1.5 - 1.25) / 0.005 = 50 ° C. The plate is equipped with holes for a thermocouple screw connection, and the goldpin connector is included.
properties
- Accuracy: ± 1 ° C for near-room temperatures, ± 2 ° C in the range -25 .. + 400 ° C
- The maximum measured temperature: 400 ° C
- Minimum measured temperature: -25 ° C
- Measuring range for 5 V supply: -250 .. + 750 ° C (0..5 V)
- Measuring range for 3.3 V power supply: -250 .. + 410 ° C (0..3,3 V)
- Power supply voltage: 3..18 V
- Size: 20 x 16 x 2 mm
- Weight: 1.1 g
The module can work with any type K thermocouple
Included
- Transducer module with AD8495 circuit
- Screw connection for self-assembly
- Goldpin connector for self-assembly
563091
Data sheet
- Interface
- Sygnał analogowy
- Type of sensor
- AD8495
- Power supply voltage
- 3 - 18 V
- Sensor type
- Termopara
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
