MT7628N-A WiFi Module – 2.4 GHz Wi-Fi communication module with 128MB RAM, 32MB Flash - Seeed Studio 317060562
ID: 1200514
5902186318328
zł80.54
Tax included
zł65.48 tax excl.
MT7628N-A WiFi Module Seeed Studio 317060562 is an energy-efficient 2.4 GHz Wi-Fi module with OpenWRT support, intended for IoT applications and integration with smart devices. Thanks to its extensive interfaces and high performance, it is used in wireless communication systems, smart home networks, and edge devices.
Description
The MT7628N-A module based on the MT7628NN chip is a low-cost and energy-efficient Wi-Fi solution for IoT applications, equipped with 128 MB RAM and 32 MB Flash memory. It supports Linux and OpenWRT operating systems, enabling flexible application development and software customization. It operates in the 2.4 GHz band with a maximum transmission speed of 300 Mbps and supports multiple operating modes, including router, access point, client (STA), and bridge.
Integrated interfaces include UART, SPI, GPIO, I2C, I2S, SDIO, Ethernet (1× WAN, 4× LAN), and PWM. The module can handle over 20 simultaneous TCP or UDP connections, and configuration can be carried out using AT commands or via a web interface. With compact dimensions and support for two external 2.4 GHz antennas, it is well suited for smart devices and cloud-based applications.
Properties
- Processor: MT7628NN
- Memory: 128 MB RAM, 32 MB Flash
- Support for Linux and OpenWRT systems
- Support for Wi-Fi IEEE 802.11b/g/n (2.4 GHz) standards
- Transmission speed: up to 300 Mbps
- Operating modes: Router / AP / STA / Bridge / AP Client
- Encryption support: WEP 64/128/152 bit, WPA/WPA2-PSK
- Antennas: 2 external 2.4 GHz antennas
- Interfaces: 1× WAN, 4× LAN, UART (3 channels), SPI, I2C, I2S, SDIO, PWM, GPIO (min. 8 lines)
- Configuration: AT commands / web interface
- Supply voltage: 3.3 V DC, current ≥800 mA
- Frequency range: 2,412–2,4835 MHz
- Transmit power: 15–20 dBm
- Operating temperature: from -20°C to +80°C
- Dimensions: 18 × 35.2 × 2.8 mm
- Certifications: FCC, CE, TELEC, IC ID
1200514
Data sheet
- Logic voltage
- 3,3 V
- Wi-Fi chip
- Inny
- Wi-Fi standard
- 802.11 b/g/n
- Frequency range
- 2,4 GHz
- Baud rate
- 300 Mbps
- Antenna connector
- Brak
- Power supply voltage
- 3,3 V
