ESP-WROOM-02 - module with ESP8266 system
ID: 563389
5906623473410
zł15.66
Tax included
zł12.73 tax excl.
Wifi module with ESPR8266 ESPRESSIF for communication in the 2.4 GHz band. It is powered by a voltage from 3 V to 3.6 V, available in an SMD enclosure. ESP-WROOM-02
Decription
ESP-WROOM-02 - module with ESP8266EX system,. Espressif is a manufacturer of this module. The company that manufactures ESP8266EX circuits, which guarantees us trouble-free operation. The module can act as a stand-alone controller, sending data using WiFi or as a device providing access to the network, relieving another processor by connecting with it using SPI / SDIO or I2C / UART.
Features
- Dimensions: 18x20x3mm
- Communication protocol: FTP, HTTP, IEEE 802.11b/g/n, TCP/IP Ver.4, UDP
- Encryption: AES, WPA, WPA2, WPS
- Transmitter power: 20dBm
- Assembly: SMD
- Bandwidth: 2.412 ... 2.484GHz
- Receiver sensitivity: b: -91dBm, g: -75dBm, n: -72dBm
- Power consumption: TX/R:170/56mA
563389
Data sheet
- Logic voltage
- 3,3 V
- Wi-Fi chip
- ESP8266
- Wi-Fi standard
- 802.11 b/g/n
- Frequency range
- 2,4 GHz
- Baud rate
- 72,2 Mbps
- Antenna connector
- Brak
- Power supply voltage
- 3 - 3,6 V
