RP2040-LCD-0.96-M - board with RP2040 microcontroller and LCD (with connectors)
search
  • RP2040-LCD-0.96-M - board with RP2040 microcontroller and LCD (with connectors)
  • RP2040-LCD-0.96-M - board with RP2040 microcontroller and LCD (with connectors)
  • RP2040-LCD-0.96-M - board with RP2040 microcontroller and LCD (with connectors)
  • RP2040-LCD-0.96-M - board with RP2040 microcontroller and LCD (with connectors)
ID: 588238
5906623422692
zł62.75
Tax included

zł51.02 tax excl.

The board with the RP2040 microcontroller equipped with two ARM Cortex-M0+ cores, which work at a frequency of 133 MHz, 264 kB RAM. The board also has 2 MB of QSPI flash memory. The system can be programmed in C/C++ or MicroPython. Waveshare RP2040-LCD-0.96-M

24h
Available
Available quantity: 4
Kamami is the official distributor of Waveshare displays, accessories and modules.


Free shipping

free shipping in Poland for all orders over 500 PLN



Same day shipping

If your payment will be credited to our account by 11:00



14 days for return

Each consumer can return the purchased goods within 14 days

Description

The board is equipped with the RP2040 microcontroller designed by the Raspberry Pi foundation. The system has two ARM Cortex M0+ cores operating at a frequency of 133 MHz and 264 KB of RAM. The microcontroller is not equipped with flash memory, but on the board there is an external memory with a capacity of 2 MB connected via the QSPI interface.

1. USB typ C  7. LiPo Charger ETA6096
2. BOOT 8. RP2040
3. RESET 9. NOR-Flash 2 MB W25Q16JVUXIQ
4. 0.96inch IPS LCD 10. DEBUG test point
5. MX1.25 battery connector 11. GPIO
6. Back Boost DC-DC TPS63000

In addition to the RP2040 system and Flash memory, the user has a 3.3 V voltage converter, Boot and Power buttons, an LCD display, a USB type C connector for powering and programming the module and GPIO outputs, on which such peripherals as 12-bit have been led out. ADC, PWM inputs, I2C, SPI and UART interface. In addition, the module has a built-in LiPo / Li-Ion charger and a connector for connecting the battery.

The platform supports the popular MicroPython and C/C++ programming languages. Programs can be uploaded to memory via USB interface or via SWD connector. The guide with examples of use is available on the product page.

Comparison table of boards with RP2040 microcontroller

Product
Raspberry Pi Pico (original)
RP2040-Zero

RP2040-LCD-0.96
RP2040-Plus
Microcontroller RP2040
Regulator/DC-DC RT6150 (DC-DC, 800mA) ME6217 (LDO, 800mA) TPS63000 (DC-DC, 1800mA)
USB Micro USB USB Type C
Flash 2 MB 4 MB
Battery connector N/A YES (with charger)
LCD N/A 0.96inch IPS LCD N/A

Features

  • RP2040 microcontroller designed by Raspberry Pi
    • Two ARM Cortex-M0 + cores clocked up to 133 MHz
    • 264 kB of onboard SRAM
  • DC-DC converter 3.3 V 1800 mA
  • Built-in USB-C connector for programming and power
  • 0.96inch 160×80 pixels 65K colorful IPS LCD display
  • 26 x multi-functional GPIO pins
    • 3 x 12-bit ADC inputs with temperature sensor
    • 16 x PWM
    • 2 x UART
    • 2 x I2C
    • 2 x SPI
  • Power and Boot buttons
  • User LED
  • 2 MB external flash memory
  • LiPo and Li-Ion charging circuit (ETA6096)
  • MX 1.25 connector for the battery
  • Supported programming languages: MicroPython and C/C++
  • Dimensions: 51 x 21 mm
588238

Data sheet

Microcontroller
RP2040
Flash memory
2 MB
Number of I/O
26
Ethernet
none
WiFi/BT module
No
Bluetooth module
No
MicroSD slot
No
Length
51mm
Width
21 mm
USB connector type
USB type C

Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
