BLDC motor driver 7-12V 1.2A
ID: 587677
5906623475551
zł53.43
Tax included
zł43.44 tax excl.
Brushless DC motor (BLDC) driver with speed control by potentiometer. It can operate motors powered with a voltage from 7 to 12 V with a current consumption of up to 1.2 A
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Brushless DC motor (BLDC) driver with speed control by potentiometer. It can operate motors powered with the voltage from 7 to 12 V with a current consumption of up to 1.2 A. It supports the control of 3-wire and 4-wire motors and allows you to adjust the motor speed and the direction of rotation (configuration by means of a jumper). The module has built-in protection against overload, short circuit and reverse polarity. Perfect as a simple BLDC motor tester, because it does not require connecting an external control board with a microcontroller.
Features
- Supply voltage: 7 to 12 V
- Working current: 1.2 A
- Speed control by potentiometer
- Configuration of the direction of movement by means of a jumper
- Supports 3-wire and 4-wire BLDC motors
- Built-in overload, short circuit and reverse polarity protection
- Dimensions: 59.5 x 44 mm
587677
Data sheet
- Output current
- 1,2 A
- Number of channels
- 1
- Supply voltage min
- 7
- Supply voltages max
- 12 V
