CM4-ETH-RS485-BASE-B baseboard for Raspberry Pi CM4 modules - Waveshare 21666
ID: 1178787
5906623426539
zł215.03
Tax included
zł174.82 tax excl.
Base board dedicated to Raspberry Pi CM4 modules. It is equipped with two RJ45 connectors, two USB 2.0, HDMI, four RS485 and CSI. Additionally, the board has an RTC system and a fan connector. Waveshare CM4-ETH-RS485-BASE-B
Description
Dual ETH Quad RS485 Base Board is a base board for Raspberry Pi CM4 modules. It is equipped with special connectors for connecting the CM4 module and the outputs of the basic interfaces, including two USB 2.0 connectors, two RJ45 Ethernet, HDMI, two CSI and 4 industrial RS485 interfaces. The board is additionally equipped with a real time clock (RTC) system, a micro SD card slot and a fan connector. Full documentation is available on the product Wiki page.
Features
- CM4 connector: suitable for all variants of the Raspberry Pi CM4 module (not included)
- 4 x isolated RS485
- Real time clock (RTC) with battery backup
- HDMI connector
- 2 x CSI MIPI Camera Connector, 15-pin 1.0mm FPC
- 2 x Gigabit Ethernet connector
- 2 x USB 2.0 connectors
- USB Type-C connector
- Micro SD card connector for RPI CM4 Lite modules
- 5V PWM fan controller with feedback
- Power LED indicators, RS485, CM4
- Power supply from 7 to 36 V
- Dimensions: 108.8 x 93.6 mm
1178787
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
