Baseboard CM4-IO-BASE-A for Raspberry Pi CM4 - Waveshare 19887
ID: 586276
5906623425563
zł83.75
Tax included
zł68.09 tax excl.
Base board dedicated to Raspberry Pi CM4 modules. It is equipped with connectors for all available interfaces. Waveshare CM4-IO-BASE-A
Description
Base board designed for Raspberry Pi CM4 modules. It is equipped with special connectors for connecting the module and the outputs of all CM4 module interfaces, including USB, Ethernet, HDMI, DSI, two CSI connectors, 40-Pin GPIO connector compatible with HAT modules. The Mini Base Board is additionally equipped with a microSD card slot. At the bottom of the board, there is also an M.2 connector for connecting additional modules or a disk, and an FFC connector with USB 2.0 and HDMI interface. Full documentation is available on the product Wiki page.
Compared to version B, the board has no RTC clock, fan controller and battery socket. The 40-pin connector is color-coded, which makes it easy to connect expansion modules. The board has compact dimensions (85 x 56 mm) corresponding to the dimensions of the Raspberry Pi 4 model B minicomputers, thanks to which, after connecting the Raspberry Pi CM4 module (not included), it can be a replacement for standard Raspberry Pi minicomputers.
Features
- CM4 connector: suitable for all variants of the Raspberry Pi CM4 module (not included)
- Standard 40-pin Raspberry Pi HAT connector
- HDMI connector
- 2 x CSI camera connector
- DSI Display Connectors
- RJ45 Gigabit Ethernet connector
- Built-in USB Hub with 2 USB 2.0 connectors
- USB type C connector for power and programming
- MicroSD card slot
- Type C USB power supply
- Dimensions: 85 x 56 mm
Kit contains
- CM4-IO-BASE-A module
- Mounting screw
586276
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
