Touch e-Paper HAT 2.13" E-Ink with touch panel for Raspberry Pi - Waveshare 19493
ID: 584588
5906623422463
zł83.94
Tax included
zł68.24 tax excl.
Module with a black and white e-Paper display with a diagonal of 2.13". It is equipped with an SPI interface for displaying an image and I2C for a touch panel. Waveshare 2.13inch Touch e-Paper HAT
Description
The module with a black and white e-Paper display with a diagonal of 2.13" and a resolution of 250x122 px. It has the ability to display content with a two-step gray scale and a partial refresh function. The built-in controller communicates with the display via the SPI interface, and the touch panel is operated by I2C interface has been used. e-Paper displays are characterized by high contrast of the displayed image and consume power only when the displayed content is changed.The module is compatible with 3.3 V systems. The board has a socket that allows you to connect the display to the Raspberry Pi via a 40-pin connector.
Features
- Diagonal 2.13"
- Resolution: 250x122 px
- Display interface: SPI
- Capacitive touch screen (5-point)
- Touch screen interface: I2C
- Tempered glass panel
- Spot size: 0.194 × 0.194 mm
- Display color: black, white
- Grayscale: 2
- Full refresh time: 2 seconds
- Refresh power: 26.4mW (typ.)
- Standby power: <0.017 mW
- Viewing angle:> 170 °
- Voltage: 3.3V
- Outline dimensions: 69.15 x 38.9 mm
- Display dimensions: 48.55 x 23.7 mm
584588
Data sheet
- Compatible with
- Raspberry Pi 5/4/3/2/1 A/B, Zero/Zero 2 H/WH
- Screen type
- E-Ink/Epaper
- Diagonal (inch)
- 2,13
- Resolution
- 250 x 122 px
- Interface
- SPI
- Touch
- No
