A01NYUB Waterproof Ultrasonic Sensor (up to 7,5m)
ID: 577435
5902186314245
zł167.65
Tax included
zł136.30 tax excl.
Ultrasonic distance sensor module with a range of up to 7.5m enclosed in a waterproof and dustproof housing. It is compatible with 3.3V or 5V devices such as Arduino, Raspberry Pi DFRobot SEN0313
Description
Waterproof ultrasonic distance sensor module with a range of up to 750 cm. It can be powered with a voltage range of 3.3 to 5 V and is compatible with 3.3 V or 5 V devices such as Arduino, Raspberry Pi etc. The average current consumption of the A01NYUB sensor is only 15 mA, so it can be powered by IO port of most controllers.
The ultrasonic sensor is enclosed in a waterproof and dustproof housing (protection class IP67), which means that it will be used in difficult and humid measuring conditions. All signal processing units are integrated in the module, communication with the module takes place via the UART interface.
An example of a sensor service code is available on the manufacturer's website.
Features
- Range: up to 750 cm
- Dead band: up to 28 cm
- Output: UART
- Response time: 100 ms
- Reference angle: 55º
- Degree of protection: IP67
- Operating voltage: 3.3 to 5 V
- Average current consumption: 15 mA
- Operating temperature: -15 to 60 ℃
- Storage temperature: -25 to 80 ℃
Kit contains
- A01NYUB Waterproof Ultrasonic Sensor
- PH2.0-4P Connector
577435
Data sheet
- Interface
- UART
- Type of sensor
- Ultrasonic
- Minimum distance
- 28 cm
- Maximum distance
- 7,5 m
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
