New products
zł732.13 tax excl.
3-color e-Paper display with a diagonal of 12.48" and a resolution of 1304x984 px. SPI interface. Without PCB. Waveshare 12.48inch e-paper (B)
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
3-color e-Paper display with a diagonal of 12.48" and a resolution of 1304x984 px. It has the ability to display content with a two-level gray scale, and the built-in controller communicates via the SPI interface. E-Paper displays are characterized by high contrast of the displayed image and consume power only when the displayed content is changed It is compatible with 3.3V systems. Support is available on the product page in the form of examples of use with Raspberry Pi, Jetson Nano, Arduino and STM32.
Features
- Diagonal: 12.48"
- Resolution: 1304x984 px
- Display color: red, black, white
- Gray levels: 2
- Interface: 3-wire SPI, 4-wire SPI
- Pixel size: 0.194 x 0.194
- Full refresh time: 16 seconds
- Power consumption: 82.5 mW
- Viewing angle:> 170 °
- No backlight, display the last content after power off
- Low energy consumption
- Working voltage: 3.3V
- Display size: 252.98 x 190.9 mm
- Outline dimensions: 261.5 x 211 x 0.3 mm
Data sheet
- Screen type
- E-Ink/Epaper
- Diagonal (inch)
- 12,48
- Resolution
- 1304x984 px
- Interface
- SPI
- Touch
- No
