ID: 1188959
zł89.00
Tax included

zł72.36 tax excl.

Serial port to Ethernet converter module based on the ESP32 series from Wireless-Tag. It integrates an optimized TCP/IP protocol stack and is characterized by extremely high performance, stability, versatility and reliability. WT32-ETH01

24h
Available
Available quantity: 13

Description

WT32-ETH01 is an innovative serial port to Ethernet converter module based on the renowned ESP32 series from Wireless-Tag. It integrates an optimized TCP/IP protocol stack, which makes networking of embedded devices extremely easy and significantly reduces programming time. Introduce innovation into your projects while saving on time and resource costs.

The module has a compact design. Thanks to the universal board width, the module can be easily soldered directly to the board or connector, giving users great installation flexibility. Moreover, the use of this module is extremely versatile, enabling both professional applications and experiments on a breadboard.


The ESP32 chip, which is the heart of the module, is an advanced 2.4 GHz Wi-Fi and Bluetooth SOC. It features extremely high RF performance, stability, versatility and reliability. Additionally, it ensures extremely low energy consumption, which makes it an ideal solution for projects that require efficient operation for an extended period of time. By choosing the WT32-ETH01 module, you invest in modernity, reliability and economy.

Features

  • Wi-Fi 802.11 b/g/n/e/i (802.11n, up to 150 Mbps), A-MPDU and A-MSDU, 2.4 GHz
  • Bluetooth v4.2 BR/EDR and BLE, NZIF radio receiver with -97 dBm sensitivity
  • RJ45 network port, 10/100Mbps
  • Serial port baud rate: 80 to 5000000 bps
  • Built-in Flash memory: 32 Mbit
  • Wi-Fi mode Station/softAP/SoftAP+station/P2P
  • Wi-Fi security WPA/WPA2/WPA2-Enterprise/WPS
  • AES/RSA/ECC/SHA encryption
  • Network protocols IPv4, TCP/UDP
  • Static IP address, DHCP (default)
  • Operating mode: TCP server, TCP client, UDP server, UDP client
  • Configuration via the AT instruction set
  • OTA firmware update over the network
  • Supply voltage: 5V or 3.3V
  • Operating current: 80 mA
  • Power supply: up to 500 mA
  • Operating temperature range: -40°C to 85°C
