The ARJM11C7-114-BA-EW2 Ethernet connector is a magnetic RJ45 module that is ideal for LAN applications. It supports data rates up to 100 Base-T with PoE (Power over Ethernet), providing a stable and efficient connection. With built-in magnetics, it effectively suppresses electromagnetic interference (EMI), making it an excellent choice for various network devices such as network cards, switches, routers, and servers

24h
Available
Available quantity: 16


Free shipping

free shipping in Poland for all orders over 500 PLN



Same day shipping

If your payment will be credited to our account by 11:00



14 days for return

Each consumer can return the purchased goods within 14 days

Description

The ARJM11C7-114-BA-EW2 Ethernet connector is a high-quality RJ45 magnetic module designed for LAN applications. It supports data transfer rates up to 100 Base-T with PoE (Power over Ethernet). Built-in magnetic circuits provide high efficiency and effective EMI (electromagnetic interference) suppression, making it an ideal solution for network cards, switches, routers, servers and other network devices

Features

  • Standard: 100 Base-T, PoE
  • Connector direction: Tab Up
  • LED: Y (yellow): G (green)
  • Operating temperature range: -40°C to 85°C
  • Soldering method: Wave, RoHS compliant
  • Dimensions: 21.30 x 15.90 x 13.60 mm
  • MSL level: 1
  • Certification: IEEE 802.3, UL compliant
  • Supported cables: CAT5, CAT6 UTP
  • Insertion loss: -1.1 dB (0.5-100 MHz)
  • Return loss: -18 dB (0.5-30 MHz), -15 dB (30-60 MHz), -12 dB (60-80 MHz)
  • Crosstalk: -35 dB (0.5-40 MHz), -30 dB (40-100 MHz)
  • CMRR: -30 dB (0.5-100 MHz)
  • DC Resistance: 1.0 Ω (Secondary Side)
  • PoE DC Current: 350 mA @57VDC continuous, 500 mA @57VDC for 200 ms
  • PoE+ DC Current: 600 mA @57VDC continuous, 720 mA @57VDC for 200 ms
