USR-TCP232-S2 - UART - Ethernet converter module
ID: 1184212
5906623438853
zł36.20
Tax included
zł29.43 tax excl.
UART - Ethernet converter enabling two-way communication between devices equipped with UART TTL ports and the Ethernet network. It is visible in the system as a virtual COM port and configured via the website or using AT commands. USR-TCP232-S2
Description
The UART - Ethernet converter is a module that enables two-way communication between devices equipped with UART TTL ports and the Ethernet network. It supports working modes: TCP Client, TCP Server, UDP Client and UDP Server as well as HTTPD Client, which allows it to be adapted to various applications.
The converter uses a built-in microcontroller with ARM Cortex-M4 core. It has a derived UART TTL interface that can work simultaneously. It supports support for all major network protocols, including IP, TCP, UDP, DHCP, DNS, HTTPS, ARP, ICMP and Web socket. It is visible in the system as a virtual COM port, which facilitates its integration with existing software. Configuration of the device is possible both via the website and using AT commands. The converter requires 3.3 V power supply and has very small dimensions, which facilitates its installation in hard-to-reach places.
Features
- Microcontroller with ARM Cortex-M0
- Bidirectional UART TTL communication with Ethernet
- UART TTL port
- UART baud rate: 600 bps to 460.8 kbps
- Supports working modes: TCP Client, TCP Server, UDP Client, UDP Server, HTTPD Client
- Visible in the system as a virtual COM port
- It can be used for communication between the microcontroller and the server via Ethernet
- Auto-MDI/MDIX, RJ45 port with 10/100Mbps
- Configuration via web page and AT commands
- Support for Modbus RTU and Modbus TCP
- Protocols: IP, TCP, UDP, DHCP, DNS, HTTPS, ARP, ICMP, Web socket
- Unique MAC address
- Electromagnetic isolation 2kV
- Small dimensions and weight
- Power: 3.3V
- Dimensions: 33 x 20.3mm
1184212
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
