ESP32 Thing Motion Shield - module with the IMU LSM9DS1 for ESP32
ID: 584173
5906623420704
zł117.93
Tax included
zł95.88 tax excl.
Module with 9-axis IMU LSM9DS1 system dedicated to ESP Thing board. Equipped with a connector for connecting GPS and a microSD slot. SparkFun DEV-14430
Description
Module with 9-axis IMU LSM9DS1 system dedicated to ESP Thing board. The system combines a 3-axis accelerometer, gyroscope and magnetometer and allows for measuring acceleration in the range of ± 2, ± 4, ± 8 or ± 16 g, angular velocity of ± 245, ± 500 or ± 2000 °/s and the magnetic field strength in the range of ± 4, ± 8, ± 12, or ± 16 gauss. These sensors allow the user to precisely measure the parameters of movement and orientation in space. In addition to the IMU system, the user has a 3-pin connector to connect a GPS receiver and a microSD card slot for data logging. Thanks to this, the module can be used to build a comprehensive device tracking the position and movement of an object. Full documentation and examples of use are available on the product page.
Features
- 3-axis accelerometer with measuring ranges of ± 2, ± 4, ± 8, ± 16 g
- 3-axis magnetometer with measuring ranges of ± 4, ± 8, ± 12, ± 16 gauss
- 3-axis gyroscope with measuring ranges of ± 245, ± 500, ± 2000 dps
- SPI/I2C serial interfaces
- Working voltage: 3.3V
- MicroSD card slot
- JST PH connector for GPS UART
