Grove 6-Axis Accelerometer & Gyroscope - module with LSM6DS3 sensor
ID: 583235
5906623414734
zł62.75
Tax included
zł51.02 tax excl.
Module with LSM6DS3 sensor that combines a 3-axis accelerometer and a 3-axis gyroscope. The board is equipped with a Grove connector and communicates via the I2C interface. Seeed Studio 105020012
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Module with LSM6DS3 sensor that combines a 3-axis accelerometer and a 3-axis gyroscope. Enables acceleration measurement with programmable measuring range of ±2/±4/±8/±16 g and measurement of rotational speed in the range of ±125, ±245, ±500, ±1000, ±2000 dps. The sensor has the ability to generate event interrupts that can be read by the user on the INT1 or INT2 pin. The board is equipped with a Grove connector, so it can be used with the Base Shield V2 and Arduino extension. The module communicates via the I2C interface and is powered with the voltage of 3.3 V or 5 V. It can be used as a sensor in mobile robots, flying objects, IoT or "wearable" devices. Full documentation of the module with examples of use is available on the product page.
Features
- Linear acceleration measurement range ±2/±4/±8/±16 g full scale (typical value)
- Angular rate measurement range ±125, ±245, ±500, ±1000, ±2000 dps(typical value)
- Linear acceleration sensitivity 0.061(FS = ±2), 0.122(FS = ±4), 0.244(FS = ±8), 0.488(FS = ±16) mg/LSB
- Angular rate sensitivity 4.375(FS = ±125), 8.75(FS = ±245), 17.50(FS = ±500), 35(FS = ±1000), 70(FS = ±2000)
- I2C interface
- I2C address: 0x6A
- Supply voltage: 3.3 V or 5 V
- Current consumption: 0.9 mA
- Dimensions: 40 x 20 x 16 mm
- Weight: 10.3 g
Kit contains
- Grove 6-Axis Accelerometer & Gyroscope module
- Grove cable
583235
Data sheet
- Interface
- I2C
- Type of sensor
- LSM6DS3
- Module type
- 6DoF
- Power supply voltage
- 3,3 - 5 V
- Sensor type
- Akcelerometr i żyroskop
