ED-HMI3010-101C-0432 - HMI module with 10.1" display, WiFi, BT, 4GB RAM and 32GB SD card
ID: 1195097
zł779.83
Tax included
zł634.01 tax excl.
The 10.1-inch industrial HMI module, based on the Raspberry Pi 5 with a Broadcom BCM2712 processor (Cortex-A76, 2.4GHz), offers 4GB RAM and a 32GB SD card, providing performance for IoT applications. The device supports 2.4/5GHz Wi-Fi, Bluetooth 5.0, 4Kp60 video output on two screens via HDMI, and is designed to work in temperatures from -20℃ to 60℃, thanks to its robust housing and fanless design. Edatec ED-HMI3010-101C-0432
Description
10.1-inch HMI module designed for industrial applications, equipped with 4 GB RAM and a 32 GB SD card, based on Raspberry Pi 5. It is a versatile solution for IoT applications. Powered by a Broadcom BCM2712 processor with a quad-core Arm Cortex-A76 architecture clocked at 2.4GHz, the device delivers sufficient performance for demanding tasks. The module supports dual-band wireless connectivity with Wi-Fi 2.4GHz and 5GHz, as well as Bluetooth 5.0, ensuring reliable connections in various working environments. Additionally, it provides 4Kp60 video output on two independent screens via dual HDMI ports.
Equipped with a Gigabit Ethernet port, 2 USB 3.0 ports, and 2 USB 2.0 ports, the module offers broad compatibility with various devices and peripherals. The 10.1-inch screen with a resolution of 1280x800 and a 16:10 aspect ratio displays 16.7 million colors, offers a brightness of 250 cd/m², and provides viewing angles of 160°/160°. The touchscreen supports 10 touch points, enabling convenient and precise control. The device is powered by 5V DC via a USB Type-C connector, with an operating temperature range from -20℃ to 60℃, ensuring reliability in harsh industrial conditions. The enclosure, made of CNC aluminum and sheet metal, and the fanless design provide efficient cooling for stable operation.
Features
- Processor (CPU): Broadcom BCM2712 2.4GHz quad-core 64-bit Arm Cortex-A76
- VPU: 4Kp60 HEVC decoder
- GPU: OpenGL ES 3.1 & Vulkan 1.2
- RAM: 4GB LPDDR4X-4267 SDRAM
- Micro SD card: 32 GB
- Wireless communication:
- Dual-band Wi-Fi (2.4GHz and 5GHz), compliant with IEEE 802.11 b/g/n/ac
- Bluetooth 5.0 with BLE support
- Operating System: Raspberry Pi OS (Desktop and Lite versions, 32-bit and 64-bit)
- Ports:
- 2 x USB 2.0 ports, dual Type-A connectors, speed up to 480 Mbps
- 2 x USB 3.0 ports, dual Type-A connectors, speed up to 5 Gbps
- Ethernet port: RJ45, adaptive (10/100/1000 Mbps)
- Micro SD card slot: supports system boot
- 2 x Micro HDMI ports, supports 4K at 60 Hz
- Power: 1 x USB Type-C port, 5V/5A DC
- PCIe 2.0 port: reserved for peripheral devices
- PoE port: reserved for PoE module
- LCD Screen:
- 10.1" TFT (1280x800)
- Backlight: LED, brightness 400 cd/m²
- Contrast: 1000:1
- MTBF: Over 30,000 hours
- Response time: 30 ms
- Viewing angle: 80°
- Multi-touch capacitive touchscreen (up to 10 touch points), I2C interface
- Input voltage: 5 V DC
- Maximum power consumption: 25 W
- Operating temperature: -20°C to 60°C
- Humidity: 5% to 95%
- Dimensions: 258 x 172 x 38 mm
- Weight: 0.9 kg
Kit contains
- HMI module
- 4 x mounts (including 4xM4*8 screws and 4xM4*16 screws)
