LattePanda Sigma - computer with Intel Core i5-1340P processor (16GB RAM, SSD, WiFi 6E)

Description

LattePanda Sigma is a computer with an Intel Core i5-1340P 13 Gen processor, which offers 12 cores and 16 threads and can run at a frequency of up to 4.6 GHz. It has a built-in Intel Iris Xe Graphics (GPU) graphics card and 16 GB LPDDR5 RAM. The device has an integrated 2.5 Gigabit Ethernet interface, USB 2.0, USB 3.2 Gen2 connectors offering data transfer speeds of up to 10 Gbps and Thunderbolt 4. The computer can support SSDs and additional 4G and 5G communication modules through three M.2 interfaces (M Key, B Key and E Key). It is equipped with an SSD with a capacity of 500 GB and a WiFi 6E module.

LattePanda is characterized by high computing capabilities, numerous interfaces, but also an ultra-thin design that allows the computer to be used in projects with limited space available. It will be used as an advanced robot controller, IoT controller or the core of a project using artificial intelligence. It will work as a home game server, multimedia server or smart home system controller.

The LattePanda Sigma computer can work under the control of the full version of the Windows 10 and 11 operating system, but also has support for the Ubuntu system. There is an ATmega32U4 microcontroller on board, which provides its GPIO lines and can be programmed using the Arduino IDE. Full documentation and necessary software are available on the product page.

Features

• Processor: Intel® Core™ i5-1340P
  • Cores/threads: 12C(4P+8E) / 16T
  • Max Turbo Frequency: 4.60GHz (Performance Core), 3.4GHz (Performance Core)
  • L2 cache: 12MB
  • Base Power: 28W
  • Graphics: Intel® Iris® Xe Graphics
  • Maximum dynamic frequency: 1.45 GHz
  • Executive units: 80
  • Coprocessor: Microchip® ATmega32U4-MU
• Memory LPDDR5-6400 16GB
• M.2 SSD (NVMe/SATA), SATA
• M.2 wireless module (PCIe/CNVio)
• HDMI port: HDMI 2.1, up to 4096 x 2304 @ 60Hz
• USB Type-C port: DP 1.4a, up to 7680 x 4320 @ 60Hz (single monitor)
• Built-in eDP 1.4b port, up to 4096 x 2304 @ 120Hz
• External inputs/outputs:
  • USB Type A: 2 x USB 2.0 (480Mbps)
  • 2 x USB 3.2 Gen 2 (10Gbps)
  • USB Type-C: 2 x Thunderbolt™ 4 (40Gbps)
  • HDMI: HDMI 2.1
  • Ethernet: 2 x 2.5GbE RJ45 ports (Intel® i225-V Gigabit Ethernet Controller, supports 10/100/1000/2500Mbps, WOL)
  • Power supply: 5.5mm x 2.5mm DC jack
  • Audio: 3.5mm headphone and microphone combo jack
  • SIM card: Micro Sim card slot
• Internal inputs/outputs:
  • USB 2.0: 2.0mm pitch 4-pin, 480Mbps
  • Fan: 1.27mm pitch, 4-wire 12V fan connector, PWM control
  • SATA: SATA 6.0Gb/s data connector, 2.0mm pitch 4-pin power connector
  • Front panel: 2.54 mm pitch 9-pin connector, supports power, reset, power LED, hard drive LED
  • Front Audio: 2.54 mm pitch 9-pin connector, supports high-definition audio (HD), line-out, microphone-in
  • COM: 2.54mm pitch 9-pin header, supports RS232, RS485
  • GPIO: 2.54mm pitch 34-pin connector including ATmega32U4 I/O pins, 5V power pins, S0/S3/S4 status pins
  • eDP: 40-pin connector, 0.5 mm pitch, 4 lanes
• Expansion Slot:
  • M.2 M key: Type 2280, supports PCIe 3.0 x4, Type 2280, supports PCIe 4.0 x4
  • M.2 Key B: type 2242/2252/2280, supports SATA III/PCIe 3.0 x1, USB2.0, USB3.0, SIM
  • M.2 E key: type 2230, supports PCIe 3.0 x1, USB2.0, Intel CNVio
• TPM: Built-in TPM (2.0)
• Power:
  • Power Input: 5.5mm x 2.1mm DC Jack: 12 to 20V, USB Type-C: PD 20V
  • Power Adapter: 19V DC, 4.74A, 90W
  • RTC battery: CR1220 Battery holder: 3V
  • 1.27mm pitch 2-pin connector: 3V
• Operating system:
  • Microsoft Windows: Windows 10, Windows 11
  • Linux: Ubuntu 22.04
• Working temperature: 0 to 45℃
• Relative humidity: 0% to 80%
• Dimensions: 3.5", 146 x 102mm

Kit contains

• LattePanda Sigma
• Active cooling fan
• Metal protective housing
• 2 x thermal pads for M.2 SSD
• Power adapter with DC cable
• Power cable
• RTC battery
• User manual
