New products
zł110.22 tax excl.
GNSS receiver module dedicated to Raspberry Pi minicomputers. It provides simultaneous reception of GPS and GLONASS satellite systems. Waveshare MAX-7Q GNSS HAT
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Expansion module with GNSS receiver dedicated to Raspberry Pi minicomputers. It provides simultaneous reception of two satellite systems: GPS and GLONASS. The module also has support for supporting systems such as SBAS and A-GNSS (Assisted GNSS).
The receiver features a high sensitivity of -161dBm. It features a high dynamic range radio circuit with analog and digital noise reduction. It uses a 56-channel u-blox 7 engine that supports GPS/QZSS L1C/A, GLONASS L1 FDMA, SBAS (WAAS, EGNOS, MSAS) frequency bands. It allows positioning with an accuracy of 2.5m for GPS and 4m for GLONASS. It also allows measurement of movement speed and direction.
1. MAX-7Q | 7. GPIO 40-pin |
2. Voltage translator 3,3V/5V | 8. UART, I2C |
3. Regulator 3,3 V | 9. USB |
4. USB-UART CP1220 | 10. Antenna connector |
5. LED Indicators | 11. UART jumper |
6. ML1220 socket |
The module has a Raspberry Pi 40-pin GPIO connector, and a UART and I2C interface that is derived, allowing connection to boards such as Arduino and STM32. It communicates at speeds from 4800 to 921600bps (9600bps by default) and has support for DDC (I2C-compatible) with a maximum frequency of 400KHz. On the bottom of the board is an ML1220 battery slot for faster measurement startup after power loss. The module is configured using the U-Center application. Full documentation and configuration examples are available on the product page.
Features
- Reception of 2 types of satellite systems: GNSS and GLONASS
- Support for supporting systems: SBAS
- A-GNSS (Assisted GNSS)
- Sensitivity: -161dBm
- Configuration via U-Center application
- Raspberry Pi 40-pin GPIO connector (compatible with Raspberry Pi, Jetson Nano)
- UART and I2C interface of the module out (can be connected to boards such as Arduino/STM32)
- Baudrate range: 4800 to 921600bps (default is 9600bps)
- Support for DDC (I2C compatible) interface: up to 400KHz (max)
- Built-in battery slot for ML1220 batteries
- 4x LEDs to indicate module operation status
- Frequency band: 56-channel u-blox 7 engine: GPS/QZSS L1C/A, GLONASS L1 FDMA, SBAS (WAAS, EGNOS, MSAS)
- Positioning accuracy: GPS: 2.5 m, GLONASS: 4 m
- Takeoff time: 29 s (cold), 1 s (hot)
- Speed measurement accuracy: 0.1 m/s
- Accuracy of direction measurement: 0.5°
- Maximum acceleration: 4g
- Maximum altitude: 50000 m
- Maximum speed: 500 m/s
- Update frequency: 0.25Hz to 10Hz (max)
- Protocol: NMEA 0183 version 4.0 (V2.3 or V4.1 selectable), UBX, RTCM 2.3
- Power supply: 5V
- Current consumption: <37mA@5V
- Module current: 17.5mA@3V
- Operating temperature -40℃ to 85℃
- Dimensions: 65 x 30.5mm
Kit contains
- MAX-7Q GNSS HAT
- GPS external antenna (B)
- USB-A to Micro-B cable
- RPi screw set (2pcs)
- 2x20PIN female connector
