Altitude/Pressure Sensor Breakout - altitude and pressure measurement module with MPL3115A2

Description

Atmospheric pressure sensor module with altitude and temperature measurement function based on the MEMS MPL3115A2 sensor. It has the ability to program events and sampling frequency (in the range from 1s to 9h). The MPL3115A2 sensor is fully internally compensated. It provides height data with an accuracy of 30 cm. The sensor outputs are converted by a high resolution 24 bit ADC and sent over I2C.

Features

• 1.95V to 3.6V Supply Voltage, internally regulated by LDO
• 1.6V to 3.6V Digital Interface Supply Voltage
• Fully Compensated internally
• Direct Reading, Compensated
  • Pressure: 20-bit measurement (Pascals)
  • Altitude: 20-bit measurement (meters)
  • Temperature: 12-bit measurement (degrees Celsius)
• Programmable Events
• Autonomous Data Acquisition
• Resolution down to 1 ft. / 30 cm
• 32 Sample FIFO
• Ability to log data up to 12 days using the FIFO
• 1 second to 9 hour data acquisition rate
• I2C digital output interface (operates up to 400 kHz)

• MPL3115A2 Datasheet (358,67 kB)
• Schematic (36,46 kB)
• Arduino Library
