zł51.10 tax excl.
RS485 bus transceiver controlled via USB, equipped with FT230 chip, USB-C connector, ST485BDR controller for 64 devices, galvanic isolation, overvoltage protection and RS485 bus terminator option, ensuring effective and safe communication in industrial systems
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
KAmod USB RS485 ISO is an RS485 bus transceiver controlled from the USB interface. On the USB interface side, there is an FT230 chip compatible with the USB 2.0 standard and a USB-C connector. On the RS485 bus side, the ST485BDR system is used, which supports up to 64 devices on the bus and is connected via circuits ensuring galvanic separation. Additionally, the module is equipped with overvoltage protection on the RS485 bus lines and allows the connection of a 120 Ω resistance acting as an RS485 bus terminator.
Features
- RS485 bus transceiver module controlled from the USB interface
- USB controller manufactured by FTDI, type FT230
- USB type USB-C connector
- Virtual serial port drivers for Win, Linux and Mac
- RS485 bus transceiver type ST485
- Half-duplex communication
- Transmission speed – max 1 Mbps
- Number of modules connected to the bus – max 64
- Signaling of data transmission/reception – LED diodes
- Switchable resistance 120 Ω (bus terminator)
- Allows you to turn on the ECHO function - transmitting and simultaneously tracking the correctness of transmission
- Galvanic separation up to 1 kV
- Overvoltage protection on RS485 bus lines
- Phoenix Contact MC 3.81 mm RS485 bus connector
- 5 V power supply via USB-C connector, current consumption max. 100 mA
- Current consumption max. 100 mA
- Mounting holes with a diameter of 2.5 mm
- Dimensions: 61 x 20 x 15 mm
