GY-6500 - accelerator and gyroscope module with MPU-6500 system
ID: 557796
5906623473274
zł10.32
Tax included
zł8.39 tax excl.
Accelerometer and gyroscope module, allows measurement of acceleration in the range of +/- 16 G and angular velocity in the range up to +/- 2000 dps. modMPU6500 (GY-6500)
Description
GY-6500 is an accelerometer and gyroscope module with I2C / SPI bus. Thanks to the built-in system, the MPU-6500 allows quick and precise measurement of angular velocity and acceleration.
properties
- Layout: MPU6500
- Power supply: 3 - 5V
- Communication modes: I2C / SPI
- Gyroscope working range: + / -250, + / -500, + / -1000, + / -2000 dps
- Accelerometer working range: + / -2G, + / -4G, + / -8G, + / -16G
- Maximum bus frequency (SPI / I2C): 1 MHz / 400 kHz
- Power consumption (gyroscope, operation): 3.2 mA
- Power consumption (gyro, sleep): 8 uA
- Power consumption (accelerometer, work): 450 uA
- Power consumption (accelerometer, sleep): 8uA
- Power supply: 3-5 V
- Dimensions: 15 x 25 mm
557796
Data sheet
- Interface
- SPI/I2C
- Type of sensor
- MPU6050
- Module type
- 6DoF
- Power supply voltage
- 3 - 5 V
- Sensor type
- Akcelerometr i żyroskop
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
