Black Magic Probe V2.3 - JTAG / SWD programmer and debugger for ARM systems + cable

Description

Black Magic Probe is an application programming and debug tool for ARM Cortex-M and ARM Cortex-A core systems. It is able to control and query the state of the target device using the JTAG or Serial Wire Debugging (SWD) port and debugging logic provided by the microprocessor. The probe connects to the host computer via a standard USB interface. The user is able to accurately control what is happening by using GNU, GDB source level debugging software. Unlike most dongles, the user does not need to use OpenOCD or STLink. Instead, the BMP is a GDB server port, emulated by the USB serial connection. In addition, the module has a built-in USB-UART converter, which enables simultaneous debugging and information transfer via one USB port. Black Magic Probe can work with most popular development environments and is supported by Linux, Mac and Windows systems. Full documentation is available on the product page.

Supported systems:

• STM32 F0, F1, F2, F3, F4, F7, G0, G4, L0, L1, L4
• Atmel SAMD20 / 21, SAM3N / S / X / U, SAM4L, SAM4S
• Nordic nRF51, nRF52
• NXP LPC8xx, LPC11xx, LPC15xx, LPC43xx
• TI LM3S, TM4C
• Freescale KL25, KL27, KL02
• Xilinx Zynq-7000
• Broadcom BCM2836 (Raspberry Pi 2)
• SiLabs EFM32 and EZR32

Features

• GDB server port without the need for any special software on the PC side
• Built-in USB-UART converter
• SWD and JTAG support
• It supports systems powered with the voltage from 1.7 V to 5 V
• It can provide a voltage of 3.3 V to the system (up to 100 mA)
• Support for semihosting
• Works on Linux, Mac and Windows
• Works with Eclipse and other integrated development environments
• Supports STM32, LPC11, LM3S
• Compatible with DroneCode

Kit contains

• Black Magic Probe module V2.3
• JTAG cable
• UART cable
