zł46.84 tax excl.
Module with a round, color IPS LCD display with a diagonal of 1.28" and a resolution of 240x240 pixels. Equipped with the GC9A01 controller. Communication is realized via the SPI interface. Waveshare 1.28inch LCD Module
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Module with a round, color IPS LCD display with a diagonal of 1.28" and a resolution of 240x240 pixels. It is equipped with the GC9A01 controller, and communication is realized via the SPI interface. It is compatible with 3.3 V and 5 V systems. On the Wiki website support is available in the form of examples of use with Raspberry Pi, Jetson Nano, Arduino and STM32.
Features
- Diagonal: 1.28"
- Display type: LCD IPS
- Controller: GC9A01
- Resolution: 240x240 px
- Communication interface: SPI
- Color: 65K RGB
- Pixel size: 0.135 x 0.135 mm
- Working voltage: 3.3 or 5V
- Dimensions (diameter): 32.4 mm
Kit contains
- 1.28inch LCD Module Display
- 8-pin PH2.0 cable 20 cm
Data sheet
- Screen type
- IPS
- Diagonal (inch)
- 1,28
- Resolution
- 240 x 240 px
- Interface
- SPI
- Touch
- No
