RP2350 development board with 1.69″ touch LCD 240×280 - Waveshare 30126
ID: 1197660
5902186307513
zł84.98
Tax included
zł69.09 tax excl.
RP2350-Touch-LCD-1.69 is a compact and versatile development board offering advanced processing capabilities thanks to its dual-core CPU architecture and large Flash memory. The integrated touchscreen, sensors, and battery power support make it an ideal choice for HMI projects, wearable electronics, measurement systems, and educational solutions based on the RP2350.
Description
The RP2350-Touch-LCD-1.69 development board, based on the RP2350 microcontroller designed by Raspberry Pi, is a compact solution for creating modern user interfaces. Equipped with a 1.69″ capacitive touchscreen with a resolution of 240×280 px, dual CPU architecture (ARM Cortex-M33 and RISC-V Hazard3), 16 MB Flash memory, a 6-axis sensor, and RTC, the board is suitable for mobile and IoT projects requiring advanced HMI functions. It supports programming in C/C++, MicroPython, and Arduino IDE.
Features
- Microcontroller: RP2350 (dual-core ARM Cortex-M33 + dual-core RISC-V Hazard3), up to 150 MHz
- Memory: 520 KB SRAM and 16 MB NOR Flash (W25Q128JVSIQ)
- Touchscreen: 1.69″ capacitive, 240×280 px, 65K colors
- Integrated 6-axis IMU (QMI8658) – accelerometer and gyroscope
- Real-Time Clock (RTC PCF85063) with backup battery connection
- Support for powering and charging 3.7 V lithium batteries (MX1.25)
- USB Type-C port supporting USB 1.1 (host/device), drag-and-drop programming
- Temperature sensor, buzzer, BOOT and RESET buttons, PWR button with multi-click functions
- Low power modes (sleep, dormant)
1197660
Data sheet
- Microcontroller
- RP2350
- Flash memory
- 16 MB
- Number of I/O
- None
- Ethernet
- none
- WiFi/BT module
- No
- Bluetooth module
- No
- MicroSD slot
- No
- Length
- 41,1 mm
- Width
- 33,1 mm
- USB connector type
- USB type C
