Kit with IoT Router Carrier Board Mini and PiTray Mini base boards for Raspberry Pi CM4 modules + case
zł294.53 tax excl.
A set with IoT Router Carrier Board Mini and PiTray Mini base boards and a housing dedicated to Raspberry Pi CM4 modules. DFRobot DFR0767-2
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
A set with base boards IoT Router Carrier Board Mini and PiTray Mini and a housing dedicated to the Raspberry Pi Compute Module 4.
The IoT Router Carrier Board Mini, when connected to the network card via PCle, provides two gigabit network ports and offers better performance and higher stability compared to the USB network card. There is a microSD card slot on the board, a USB type C connector for power supply, USB 2.0 type C for connecting external devices and a 26-pin connector compatible with the Raspberry Pi. It can be used with the OpenWRT system and can be used as a router after simple configuration. It is also compatible with Raspberry OS, Ubuntu Server, and other systems.
PiTray Mini is the base board for building a cluster with the Raspberry Pi 4 CM4 computing module. It has the same dimensions and mounting holes as the Raspberry Pi Model B, so it can be set up on top of an existing cluster. CM4 has an advantage over the Raspberry Pi 4B in industrial applications. The board has an eMMC starter switch and a micro SD card slot for CM4 Lite. Besides, it provides one USB2.0 connector, full size HDMI and HAT connector.
Features
IoT Router Carrier Board Mini
- 2 x Ethernet connector
- USB Type-C connector for power
- USB Type-C connector (USB 2.0 High Speed)
- MicroSD slot (without eMMC support)
- 26-pin GPIO connector, compatible with Raspberry Pi
- Power supply: USB type C 5V / 3A
- Working temperature: 0 ℃ to 80 ℃
- Dimensions: 55 x 62 mm
PiTray Mini
- CM4 socket
- Raspberry Pi HAT connector
- Standard HDMI 2.0
- Gigabit Ethernet RJ45 socket
- Native USB 2.0 connector
- SD card slot for CM4 variants without eMMC
- USB Type-C connector for power supply as well as programming of the eMMC CM4 variants
- Boot mode switch for programming mode and normal mode
- RUN button
- Power LED red
- Green activity LED
- Mounting holes for CM4
- Power supply: 5V
- Dimensions: 85 x 56 mm
Case
- Material: acrylic
- Dimensions: 78 x 72 x 35 mm
- Designed for the IoT Router Carrier Board Mini
- Aluminum heat sink
Kit contains
- IoT Router Carrier Board Mini
- PiTray Mini
- Acrylic case
