ID: 1183451
5906623435067
zł975.00
Tax included

zł792.68 tax excl.

Digital oscilloscope. It has two measurement channels with 150 MHz bandwidth. Hantek DSO2C15

4 weeks
Awaiting delivery
Oscilloscope version DSO2:
DSO2D15
DSO2C15
DSO2C10 DSO2D10
Kamami is the official distributor of Hantek oscilloscopes and accessories. All products of this brand in our offer are original and come directly from the manufacturer.

Description

Digital oscilloscope. It features a 7" TFT LCD display with 800 x 480 pixel resolution and adjustable backlight brightness. It has two measurement channels and features good performance, including a bandwidth of 150 MHz, a sampling rate of 1 GSa/s and a memory buffer of 8 M. It has numerous built-in functions to facilitate signal analysis, including AUTOSET auto-setting, measurement of 32 voltage-time parameters, serial bus decoding (RS232/UART, I2C, SPI, CAN, LIN), FFT analysis, X-Y operation, waveform recording and communication with a PC via a USB interface. Besides, it supports SCPI remote control commands. It is a useful measurement tool widely used in various fields such as communications, aerospace, embedded systems, computers, research and education.

Features

Oscilloscope

  • Number of channels: 2
  • Sampling frequency: 1GSa/s (single channel) 500MSa/s (two channels)
  • Resolution: up to 12 bits
  • Input coupling: DC, AC, GND
  • Input impedance: 1MΩ±2% ‖20pF±3pF
  • Probe attenuation coefficient: 1X, 10X, 100X, 1000X
  • Voltage rating: 300V CAT II
  • Maximum input voltage: 300VRMS (10X)
  • Horizontal:
    • Waveform interpolation: (sin x)/x
    • Maximum recording length: 8M (one channel), 4M (two channels)
    • Horizontal scale range: 2ns/div~100s/div 1, 2, 5 step by step
    • Time base mode: Y-T, X-Y, Roll
    • Zero offset: ±0.5 div x minimum time base run
    • Sampling frequency and delay time measurement accuracy: ±25ppm
  • Vertical:
    • Frequency bandwidth: 150 MHz
    • Rise time: 2.4 ns
    • Vertical resolution: 8 bits, each channel samples simultaneously
    • Vertical sensitivity: 2mV/div to 10V/div
    • Offset range ≥ 200mV/div, ±1V, ＜200mV/div ±50V
    • Mathematical operations: +, -, ×, ÷, FFT
    • FFT window: Rectangle, Hanning, Hamming, Blackman, Bartlett, Flattop
    • Bandwidth limit: 20 MHz
  • Triggering:
    • Trigger type: edge, pulse width, slope, timeout, window, pattern, interval, UART, LIN, CAN, SPI, IIC
    • Trigger level range: ±5 divisions from the center of the screen
    • Trigger mode: Auto, Normal, Single
    • Hold range 8ns to 10s
  • Measurement
    • Voltage difference between cursors △V
    • Time difference between cursors △T
    • Inverse △T, in hertz (1/△T)
    • Automatic measurement: frequency, period, average, peak-to-peak, RMS, minimum, mixmum, rise time, fall time, + width, - width, base, top, middle, amplitude, overshoot, preshoot, rising edge phase difference, falling edge phase difference, + duty, - duty, period average, PRMS, FOVshoot, ROVshoot, BWIDTH, FRF, FFR, LRR, LRF, LFR, LFF
    • DC RMS, AC RMS, DC measurement type.
    • Frequency measurement: 6-bit

General parameters

  • TFT color LCD display with 7" diagonal and 800 x 480 pixel resolution with adjustable backlight brightness
  • Interface: USB Host，USB Device
  • Probe compensation output
  • Output voltage: 2Vpp input ≥1MΩ load
  • Frequency: 1kHz
  • Power supply: 100-120 VAC RMS(±10%), 45Hz to 440Hz, CATⅡ, 120-240VACRMS(±10%), 45Hz to 66Hz, CATⅡ
  • Power consumption: <30W
  • T fuse, 3.15A, 250V, 5x20mm
  • Operating temperature: 0 to 50 °C
  • Dimensions: 318 x 110 x 150 mm
  • Weight: 1900 g

Kit contains

  • Oscilloscope
  • Test leads
  • USB cable
  • Power supply cable
1183451

Data sheet

Type of oscilloscope
Digital
Bandwidth
150 MHz
Sampling rate
1 Gsps
Memory depth
8 Mpts
Number of channels
2
