ProS3 - WiFi and BLE module with ESP32-S3
search
  • ProS3 - WiFi and BLE module with ESP32-S3
  • ProS3 - WiFi and BLE module with ESP32-S3
  • ProS3 - WiFi and BLE module with ESP32-S3
  • ProS3 - WiFi and BLE module with ESP32-S3
ID: 1179385
5906623431144
zł173.04
Tax included

zł140.68 tax excl.

Module with WiFi and BLE Espressif ESP32-S3. It integrates a LiPo charging circuit and an RGB diode. Equipped with a STEMMA QT connector. Adafruit 5401

24h
Available
Available quantity: 1
Kamami is the official distributor of Adafruit modules and development kits. All boards of this brand in our offer are original and come directly from the manufacturer.


Free shipping

free shipping in Poland for all orders over 500 PLN



Same day shipping

If your payment will be credited to our account by 11:00



14 days for return

Each consumer can return the purchased goods within 14 days

Description

Module with WiFi Espressif ESP32-S3. It has 16 MB of Flash memory, 8 MB of external PSRAM, integrated WiFi 802.11 b/g/n and BLE transceiver and pins for connecting a LiPo battery. There is an RGB diode on the board. The module is equipped with two 3.3 V stabilizers with a capacity of 700 mA and is powered by a USB type C connector. It can be integrated with sensors due to the available STEMMA QT connector (compatible with Qwiic).

The module offers great possibilities in the field of IoT systems and can be used both to control LEDs and to transfer data to a specific platform. It can be programmed using Arduino IDE, ESP-IDF or CircuitPython.

Features

  • 240MHz 32-bit dual-core processor
  • 16 MB SPI Flash Memory
  • 8 MB of PSRAM
  • Wi-Fi 2.4 GHz - 802.11b/g/n
  • Bluetooth 5, BLE + Mesh
  • 3D antenna
  • Optimized power system ensuring low energy consumption
  • Manage LiPo battery charging
  • USB Type-C with reverse power protection
  • RGB LED
  • Picoblade connector (LiPo battery)
  • LED indicator for charging, power
  • 27 GPIO pins
  • Reset button and Boot
  • STEMMA QT connector
  • JTAG pins
  • 2 x 3.3 V 700 mA regulator

Kit contains

  • ProS3 module
  • 2 x 17-pin goldpin male connector
  • Battery cable
