ESP32-S3-LCD-5B is a high-performance development board with a 5-inch high-resolution display, offering extensive communication capabilities and external power input in the range of 7–36 V. With expanded memory, isolated inputs/outputs, and support for Wi-Fi and Bluetooth, it is suitable for industrial HMI systems, smart control panels, and IoT projects where touch functionality is not required.

24h
Available
Available quantity: 1
Kamami is the official distributor of Waveshare displays, accessories and modules.

Description

ESP32-S3-LCD-5B is an extended version of the development board with the ESP32-S3 microcontroller, featuring a 5-inch IPS display with a resolution of 1024×600 px and a wide 178° viewing angle. The module offers a dual-core Xtensa LX7 processor clocked up to 240 MHz, 2.4 GHz Wi-Fi connectivity, and Bluetooth 5 LE with a built-in antenna. It includes 16 MB of Flash memory, 8 MB of PSRAM, and a rich set of communication interfaces: CAN, RS485, I2C, USB, TF card slot, and opto-isolated digital inputs/outputs. A built-in RTC with battery backup ensures continuous timekeeping. This board is ideal for advanced HMI projects, industrial automation, and embedded systems that do not require touch support.

Specifications

  • Processor: Xtensa 32-bit LX7 dual-core, up to 240 MHz
  • Wireless: Wi-Fi 2.4 GHz (802.11 b/g/n) and Bluetooth 5 LE
  • Memory: 512 KB SRAM, 384 KB ROM, 8 MB PSRAM, 16 MB Flash
  • Display: 5" IPS, resolution 1024×600, 178° viewing angle, 65K colors
  • TF card slot for data and image storage
  • Interfaces: CAN, RS485, I2C, USB Type-C
  • Digital inputs: 5–36 V (NPN/PNP, bidirectional opto-isolation)
  • Digital outputs: 5–36 V, open collector, up to 450 mA per channel
  • Power supply: USB Type-C or 7–36 V DC terminal
  • RTC with battery backup
  • LED indicators for power and battery charging status
  • Supports precise control of system clock and power modes
